ROBOT CELL WITH FLEXIBLE COMPONENT FEEDERS
- Fully automatic robotic cell incl. pad printing and assembly station
- 3D position detection of loosely poured components by means of reaching into the crate / 3D bin picking
- Highest possible degree of flexibility with a high number of variants
- Components are placed on the rotary table in tenths of a millimeter thanks to fully automatic, collision-free path planning
- Flexible component feeding by means of feeder system and camera technology for the small parts
- Easy integrability of new component types ensures high customer benefit even beyond the life cycle of individual products
ASSEMBLY AND TESTING SYSTEM FOR INDEXABLE INSERTS
- Robot cell for position-oriented placement of hard material segments
- Stacking and unstacking system for customer trays
- Flexible and position-oriented feeding of the hard material segments by means of vibration and camera system
- Spot or bead solder paste application adapted to component contour
- Precise dosing of very small quantities
- Inline measurement during joining process to actively influence positioning
- 100% control of the finished components
- Positioning by means of laser profile sensor
- Dosing by means of camera system
AUTOMATIC RELOADING CELL FOR CARBIDE RODS
- Automatic reloading cell for carbide rods
- High degree of autonomy
- Stacking magazines for component crates
- Automated insertion of separators into crates
- Component cassettes have RFID system
- Combination of robot handling and electric axis gantries
- Magnetic gripper system for component handling (in-house development)
- SAP connection
Soldering robot SX
- Soldering system for SX molds
- Automatic dosing application of smallest quantities (punctual or linear)
- Feeding of components via drawer system and customer baskets
- Position and rotation determination of the components by means of camera and illumination system
- Solder foil is supplied and separated as bulk material by means of a vibratory feeder including integrated camera system
- Integrated inline soldering station with pyrometer monitoring
